STEREO HYBRID ONE44 HPC
SLT 800

SRP* 105990 NOK

ArtNo. 102900

carbongrid´n´chrome

Comparison

TRAILS,
YOUR WAY

A great bike is all about the detail, and the Stereo Hybrid ONE44 HPC's frame is chock-full of clever details. You'll notice the Internal Cable Routing because it so neatly complements the High Performance Carbon main triangle's clean lines, while the angle-adjustable headset means you can tailor the handling to your specific requirements. A Direct Mount chain guard keeps the gears on the straight and narrow, and the neatly integrated Bosch top tube controller plus Purion 400 display show you what's going on with the powerful Bosch CX-R drive and 800Wh PowerTube battery at a glance. With a 150mm fork and 140mm of rear-wheel travel, it's ready to take on the toughest of trails. The UDH dropout means it's future-proof, too. And, with Size Split, there's a wide range of sizes to suit most riders.

Frame Material

High Performance Carbon

Battery

800Wh

Sizes

Size Split

Highlights

Big mountain trails take no prisoners. That's why we equipped the Stereo Hybrid ONE44 HPC SLT 800 with the best of the best. From Sram's 12-speed XX Eagle Transmission to the Fox suspension and Bosch CX drive with 800Wh battery, it's all designed to bring you out on top and wearing a huge grin.

The Stereo Hybrid ONE44 HPC SLT 800 represents the ultimate all-mountain e-MTB, so we equipped it appropriately. The 150mm Fox 36 Float Factory fork and 140mm of rear-wheel travel from the Float X Factory shock keep the 2.5in Schwalbe Albert tyres where they should be: rubber side down, and rolling smoothly on the Newmen Phase 30 wheelset. Powerful, progressive Magura Gustav Pro hydraulic disc brakes give fingertip speed control. A Race Face Era carbon crank gets your power to the trail via Sram's XX Eagle Transmission 1x12 gears, helped by up to 100Nm of torque from the Bosch CX-R drive and 800Wh battery. And the remote dropper post gives you the best-possible control on steep, tough trails. Zero compromise, maximum performance: all-mountain fun, all of the time.

Frame

frame

C:62® Monocoque Advanced Twin Mold Technology, Aluminium 6061 T6 Rear Triangle, Efficient Trail Control, FSP 4-Link, Agile Trail Geometry, Boost 148, UDH™, Full Integrated Battery, Advanced Internal Cable Routing

The Fully Integrated Battery system tucks the power of Bosch's battery out of sight, safely inside the confines of your bike's downtube. Hidden beneath a splash and dust-proof cover and secured with a lock to prevent theft, it allows us to design beautiful e-bike frames that are as brilliantly functional as they are good to look at.

Gear and brake cables need a way to get from handlebar controls to frame – but what if there was no need for holes near the head tube? We came up with a design that takes cables into the frame via the headset, maintaining full internal cable routing but making it even neater and less obtrusive.

In many ways the battery is the heart of an e-bike. That's why, with our Modular Battery System, we've made a setup that's easy to use. You can charge the battery on or off the bike, and we've made room for even high capacity batteries. You'll wonder how you ever managed without it.

When you're harnessing gravity, the trail is challenging and every second counts, the geometry of your CUBE is a critical component. That's why our adjustable headset allows you to tweak head angle, so you can set your bike up just the way you like it. A little slacker for more stability, or a little steeper for better agility. The choice is yours...

Agile Trail Geometry is a development of our popular and well received Agile Ride Geometry, with a focus on riders who enjoy pushing their limits on the trails. By lowering standover height and allowing more room for the rider to move around over the bike, we've created a setup that rewards adventurous line choices. Because, after all, it's all about having fun.

HPC – high performance carbon – enables us to build lighter, stronger and stiffer frames out of this incredibly versatile material. Using a combination of careful frame design and variable lay-up thickness, we're able to fine-tune the performance of each frame to precisely meet our requirements for weight, stiffness, strength and durability.

X-Connect is the simple way to attach a compatible ACID light to your CUBE bike. With a connector built into the headset and the wiring hidden in the frame, all that's left to do is attach the light, plug it in... and off you go. See and be seen, the easy way.

size

Size Split: 27.5: S // 29: M, L, XL

Suspension

Suspension fork

Fox 36 Float Factory GRIPX2, Tapered, 15x110mm, E-Bike Optimized, 150mm

shock

Fox Float X Factory, 230x60mm (27.5: 210x55mm), Adjustable LSC/LSR w/ 2-Pos. Lever

shock hardware

Front: 30x8mm, Rear: DU-Bushing 12.7mm

E-bike system

drive unit

Bosch Drive Unit Performance Line CX-R 100Nm (BDU38)

Remote

Bosch Mini Remote

battery

Bosch PowerTube 800

display

Bosch Kiox 400C

charger

Bosch 4A

Drivetrain & brakes

brake system

Magura Gustav PRO, Front 4-Piston/Rear 4-Piston, Hydr. Disc Brake (203/203)

rear derailleur

Sram XX Eagle AXS™ Transmission, 12-Speed, Electronic Shifting System

shifters

Sram AXS™ Pod Ultimate Controller

crankset

Race Face ERA E-MTB, 27.5: 36T // 29: 34T

cassette

Sram XS-1297, 10-52T

chain

Sram XX Eagle Transmission

chain guide

Reverse Flip-Guide E-Chain Guide, Direct Mount, I-Plate

Cockpit

headset

ACROS AZF-675, ICR (Integrated Cable Routing), Top Zero-Stack 1 1/2" (ZS 56mm), Bottom Zero-Stack 1 1/2" (ZS 56mm), Fiber Inserts for Angle Adjustment, X-Connect Interface

Stem

CUBE Performance Stem E-MTB 35, FPI-Link

handlebar

Race Face ERA 35

grips

ACID Disrupt

Wheels

wheelset

Newmen Phase 30 base/strong, 28/28 Spokes, 15x110mm/12x148mm, Tubeless Ready

front tyre

Schwalbe Albert Trail Pro, Addix Soft, Kevlar, 2.5

rear tyre

Schwalbe Albert Gravity Pro, Addix Soft, Kevlar, 2.5

Finishing kit

saddle

ACID Venec EMTB Trail 140

seat post

Fox Transfer Factory 31.6mm, Kashima Coated

pedals

ACID PP MTB

extras

Schwalbe Aerothan™ Inner Tubes w/ ClikValve

Product information

colour

carbongrid´n´chrome

weight

23,4 kg

Art. No

102900

SRP*

105990 NOK

*Suggested retail price

Due to unforeseeable supply chain issues, the bike may be delivered with modifications.

More Information

Bike category of use: 4

You can find more information about Bike Classification at the following link.

More Information

125
kg

Maximum rider weight

The rider weight refers to the weight of the rider including clothing and any equipment worn on the body.

Please see the table for information on the distribution of weight across the system in conjunction with compatible accessories (luggage carriers, bike trailers, etc.).

System weight table

Geometry

Slack/Moderate	S	M	L	XL
Seat tube	370	405	420	480
Top Tube Horizontal	566 / 568	596 / 598	626 / 627	669 / 671
Seat angle	76.2° / 76°	76.2° / 76°	76.2° / 76°	76.2° / 76°
Head tube angle	64.8° / 64.4°	64.8° / 65.4°	64.8° / 65.4°	64.8° / 65.4°
Chainstays	450	457	457	457
Head tube	128	106	120	148
Wheelbase	1204 / 1196	1233 / 1226	1264 / 1256	1311 / 1303
BB-Height to Hub	12 / 11	30	30	30
Protrusion height - 80mm	733	748	748	748
Reach	427 / 425	452 / 450	477 / 475	512 / 510
Stack	604 / 606	620 / 622	632 / 634	658 / 660

Ergonomics

	S	M	L	XL
Stem length	50	50	50	50
Angle stem	12°	12°	12°	12°
Handlebar width	780	780	780	780
Crank length	165	165	165	165
Length seat post	411	411	476	541
Diameter seatpost	31.6	31.6	31.6	31.6
Max. insertion depth seat post	220	230	250	310
Stroke seatpost	150	150	180	210
Diameter tire maximum	721	759	759	759
Width tire maximum	67	67	67	67
Rear suspension travel	140	140	140	140
