NULANE
RACE

SRP* 12490 NOK

ArtNo. 156300

amber´n´black

Comparison

COMMUTE.
TRAIN.
EXPLORE.

Versatile can be fast, and fast can be versatile, too. That's why, with the Nulane frame, we added mounting points for easy mudguard and carrier upgrades. There are even lowrider rack points on the full carbon fork, so it's practical as well as comfortable. Superlite double-butted aluminium frame tubes keep the weight down. We added flat mount disc attachment points for sleek looks and the best stopping performance. And finished off with thru axles front and rear to ensure safe and predictable handling, laden or unladen.

Frame Material

Aluminium Superlite

Tire clearance

45mm

Highlights

The Nulane Race's light, nimble frame and full carbon fork borrows from our road bike heritage, so it's fast. Hydraulic disc brakes plus mounting points for mudguards and a luggage carrier mean it's versatile. And we made it rugged, too, because that's what we do. Have your cake and eat it.

Keep it simple, but keep your options open, too. The Nulane Race's blend of low weight and practicality makes it a force to be reckoned with on city streets, country lanes and gravel tracks alike. Shimano's Cues 2x10 gears serve up a wide range of ratios and clean shifting in a durable, light package. Powerful hydraulic disc brakes ensure you've always plenty of power on hand to stop safely, even if the weather's throwing you a curve ball. And the comfortable full carbon fork, 40mm Schwalbe G-One tyres and easy accessory upgradeability seal the deal.

Frame

frame

Aluminium Superlite Trekking Sport, Flat Mount Disc, 12x142mm, AXH

A gravel bike is a supremely versatile beast, which is why all our gravel models have a fender and rack option. With generous frame clearances to fit comfortable, safe and grippy tyres even with full length mudguards, we also neatly integrated the rear rack into the mudguard design – and included a rear light, too.

Combining everything we know about building great-riding off-road bikes, Gravel Comfort Geometry is the secret ingredient that makes our gravel series such a blast to ride. Nimble enough to mix it up in the rough, stable enough for reassuring descents and with comfort for the long haul, we've got it all covered.

Cables for your gears and brakes are essential, but you don't necessarily want to see them all the time. Our semi internal cable routing takes gear and brake cables through the down tube for a cleaner appearance, smoother shifts and reduced maintenance. So your CUBE bike looks good and continues to function as it should, and you just concentrate on enjoying the ride.

CUBE's Aluminium Superlite starts with heat-treated 6061 aluminium, which has the qualities – high fatigue resistance, good stiffness, low weight and excellent strength – that are important for a bicycle frame. Then we make it into double butted tubes, to reduce weight without sacrificing any of its strength. The result? Exceptionally light, strong and tough frames.

size

Classic: 50cm, 53cm, 56cm, 59cm, 62cm

fork

CUBE TS Disc, Full Carbon, Taper, Flat Mount, 12x100mm

Drivetrain & brakes

brake system

Tektro HD-R280, Hydr. Disc, Flat Mount (160/160)

rear derailleur

Shimano Cues RD-U6020-SGS, 10-Speed

shifters

Shimano Cues SL-U6000, Rapidfire-Plus

front derailleur

Shimano Cues FD-U6010, Top Swing, 31.8mm

bottom bracket

Shimano BB-MT500PA, 92mm Pressfit

cassette

Shimano Cues CS-LG400, 11-39T

chain

KMC xGlide

Cockpit

headset

VP Z-t, Top Zero-Stack 1 1/8" (OD 44mm), Bottom Integrated 1 1/4"

Stem

CUBE Performance Stem SLX, FPI-Link, 31.8mm

handlebar

CUBE Flat Race Bar, 660mm

grips

ACID Travel

Wheels

wheelset

CUBE RA 2.3 Aero Disc

tyres

Schwalbe G-One R Pro, Evolution, V-Guard, 40-622

Finishing kit

saddle

ACID Nuance Lite

seat post

CUBE Performance Post, 27.2mm

pedals

ACID PP Trekking

Product information

colour

amber´n´black

weight

10,9 kg

Art. No

156300

SRP*

12490 NOK

*Suggested retail price

Due to unforeseeable supply chain issues, the bike may be delivered with modifications.

More Information

Bike category of use: 2

You can find more information about Bike Classification at the following link.

More Information

100
kg

Maximum rider weight

The rider weight refers to the weight of the rider including clothing and any equipment worn on the body.

Please see the table for information on the distribution of weight across the system in conjunction with compatible accessories (luggage carriers, bike trailers, etc.).

System weight table

Geometry

	50 cm	53 cm	56 cm	59 cm	62 cm
Seat tube	460	490	520	550	580
Top Tube Horizontal	542	566	574	593	612
Seat angle	74°	73°	73°	73°	73°
Head tube angle	70.5°	71.5°	72°	72°	72°
Chainstays	442	442	442	442	442
Head tube	137	157	172	197	227
Wheelbase	1044	1049	1052	1072	1091
BB-Height to Hub	60	60	60	60	60
Protrusion height - 80mm	753	780	804	831	860
Reach	385	391	395	406	416
Stack	548	571	587	611	640

Ergonomics

	50 cm	53 cm	56 cm	59 cm	62 cm
Stem length	70	70	90	90	90
Angle stem	6°	6°	6°	6°	6°
Handlebar width	660	660	660	660	660
Crank length	170	170	170	175	175
Length seat post	350	350	350	350	350
Diameter seatpost	27.2	27.2	27.2	27.2	27.2
Diameter tire maximum	711	711	711	711	711
Width tire maximum	42	42	42	42	42
