NULANE
ONE

SRP* 8790 NOK

ArtNo. 156100

indigoblue´n´black

Comparison

COMMUTE.
TRAIN.
EXPLORE.

The Nulane's blend of practicality, ruggedness and pace is built into every feature of its double-butted aluminium frame. With quick-release wheels for easy transport or storage, it also features mudguard and rack mounting points for an easy upgrade to touring or commuting duties. Disc mounts are standard, of course, and the full carbon fork adds comfort and accurate steering to the mix.

Frame Material

Aluminium Superlite

Tire clearance

50mm

Highlights

The Nulane ONE isn't your average road bike, but nor is it a normal tourer. Road bike-inspired pace, a responsive frame and carbon fork add up to easy speed. Flat bars, a luggage carrier and mudguard mounting points equal simple practicality. It's an urban assault machine and a rugged explorer, combined.

The Nulane ONE takes the race-inspired DNA of our road bikes, adds some touring bike practicality and throws in a dose of flat bar ruggedness. The result? A uniquely capable go-anywhere, do-anything bike. Powerful Shimano hydraulic disc brakes offer progressive, reassuring stopping power in any weather conditions. Shimano's simple Essa 1x8 gears will get you there – and back. And the comfortable, lightweight full carbon fork helps smooth your way, even on rougher roads. It's the complete package, wherever you're headed.

Frame

frame

Aluminium 6061 T6 Superlite, Gravel Comfort Geometry, Flat Mount Disc, Fender & Rack Option, QR

A gravel bike is a supremely versatile beast, which is why all our gravel models have a fender and rack option. With generous frame clearances to fit comfortable, safe and grippy tyres even with full length mudguards, we also neatly integrated the rear rack into the mudguard design – and included a rear light, too.

Combining everything we know about building great-riding off-road bikes, Gravel Comfort Geometry is the secret ingredient that makes our gravel series such a blast to ride. Nimble enough to mix it up in the rough, stable enough for reassuring descents and with comfort for the long haul, we've got it all covered.

Cables for your gears and brakes are essential, but you don't necessarily want to see them all the time. Our semi internal cable routing takes gear and brake cables through the down tube for a cleaner appearance, smoother shifts and reduced maintenance. So your CUBE bike looks good and continues to function as it should, and you just concentrate on enjoying the ride.

CUBE's Aluminium Superlite starts with heat-treated 6061 aluminium, which has the qualities – high fatigue resistance, good stiffness, low weight and excellent strength – that are important for a bicycle frame. Then we make it into double butted tubes, to reduce weight without sacrificing any of its strength. The result? Exceptionally light, strong and tough frames.

size

Classic: 50cm, 53cm, 56cm, 59cm, 61cm

fork

CUBE Nuroad Flat Mount Disc, Full Carbon, 1 1/8" - 1 1/4" Tapered, Fender & Lowrider Mounts, QR

Drivetrain & brakes

brake system

Shimano BR-MT200/UR300, Hydr. Disc Brake, PM/FM (180/180)

rear derailleur

Shimano Essa RD-U2000-GS, 8-Speed

shifters

Shimano SL-M315, Rapidfire-Plus

bottom bracket

Thun Paso-ML, 68mm, BSA

crankset

Shimano Essa FC-U2000-1, 40T

chain

KMC Z51

Cockpit

headset

VP Z-t, Top Zero-Stack 1 1/8" (OD 44mm), Bottom Integrated 1 1/4"

Stem

CUBE Performance Stem SLX, FPI-Link, 31.8mm

handlebar

CUBE Flat Race Bar, 660mm

grips

ACID Travel

Wheels

rims

ACID EX25, 32H, Disc, Tubeless Ready

front hub

Shimano HB-QC300, QR, Centerlock

rear hub

Shimano FH-QC300-HM, QR, Centerlock

tyres

Schwalbe G-One Comp, ActiveL, 40-622

Finishing kit

saddle

ACID Nuance Lite

seat post

CUBE Performance Post, 27.2mm

pedals

ACID PP Trekking

Product information

colour

indigoblue´n´black

weight

11,6 kg

Art. No

156100

SRP*

8790 NOK

*Suggested retail price

Due to unforeseeable supply chain issues, the bike may be delivered with modifications.

More Information

Bike category of use: 2

You can find more information about Bike Classification at the following link.

More Information

100
kg

Maximum rider weight

The rider weight refers to the weight of the rider including clothing and any equipment worn on the body.

Please see the table for information on the distribution of weight across the system in conjunction with compatible accessories (luggage carriers, bike trailers, etc.).

System weight table

Geometry

	50 cm	53 cm	56 cm	58 cm	61 cm
Seat tube	470	500	530	550	580
Top Tube Horizontal	519	537	560	575	592
Seat angle	75.7°	74.7°	73.9°	73°	73°
Head tube angle	69°	70°	71°	71.5°	72°
Chainstays	440	440	440	442	442
Head tube	120	145	177	197	220
Wheelbase	1045	1045	1052	1054	1066
BB-Height to Hub	70	70	70	70	70
Protrusion height - 80mm	755	786	809	830	857
Reach	382	383	387	386	396
Stack	537	564	598	619	643

Ergonomics

	50 cm	53 cm	56 cm	58 cm	61 cm
Stem length	80	80	90	100	100
Angle stem	6°	6°	6°	6°	6°
Handlebar width	660	660	660	660	660
Crank length	170	170	172.5	172.5	175
Length seat post	350	350	350	400	400
Diameter seatpost	27.2	27.2	27.2	27.2	27.2
Diameter tire maximum	732	732	732	732	732
Width tire maximum	53	53	53	53	53
