NATURE
SLX

ArtNo. 860401

Comparison

GET OUT
MORE

Your bike should be a pleasure to ride, which is why we pulled out the stops to make the Nature's frame as light as possible without sacrificing strength. The secret is double-butted aluminium tubes, with Smooth Welded joints for a neat, tidy finish. It's all tested in our in-house lab, so you can be assured it's up to the job. We built in clearance for tyres up to 50mm in width, which helps ensure a comfortable ride. There's a tapered head tube for precise steering, and sleek luggage carrier and mudguard mounting points for future upgrades. It's everything you need for carefree days out in the countryside.

Frame Material

Aluminium Superlite

Nothing quite beats the feeling of bowling along a country lane on two wheels at the weekend. With its lightweight frame, easy handling and reliable Shimano components, the Nature SLX is your gateway to that sense of freedom and adventure.

NATURE

You never quite know where the road less travelled will lead you. It could be smooth, or gravel, or dusty and full of potholes. That's what our Trekking Cross Geometry is designed to handle: any road, in any condition, any time. With plenty of room for grippy, wide tyres and handling that's both nimble and safe, you're in good hands wherever you're headed.

At CUBE we believe even a functional bike should be attractive. The carrier and mudguard mounting points for our Nature series are designed specifically to provide a strong, secure anchor point for these useful accessories. But they're also unobtrusive and elegant, so your bike still looks great.

Smooth Welding isn't easy, but worthwhile things usually aren't. It has two advantages. First, and most obviously, it looks great: one tube seems to almost flow into the other. Second, and at least as importantly, it helps to minimise load peaks on welded areas for better frame strength and durability.

Cables for your gears and brakes are essential, but you don't necessarily want to see them all the time. Our semi internal cable routing takes gear and brake cables through the down tube for a cleaner appearance, smoother shifts and reduced maintenance. So your CUBE bike looks good and continues to function as it should, and you just concentrate on enjoying the ride.

Frame

frame

Aluminium Superlite, Trekking Cross, Taper, Double Butted

size

Trapeze: XS / 46cm, S / 50cm, M / 54cm

Suspension

Suspension fork

SR Suntour NCX E RL Air T, 63mm, Remote Lockout

Drivetrain & brakes

brake system

Shimano Cues BR-U8000, Hydr. Disc Brake (180/160)

rear derailleur

Shimano Cues RD-U8020-SGS, 11-Speed

shifters

Shimano Cues SL-U8000-I, Direct Attach, Rapidfire-Plus

front derailleur

Shimano Cues FD-U8010, Top Swing, 31.8mm

bottom bracket

Shimano BB-MT501, 68mm BSA

crankset

Shimano Cues FC-U8000, Hollowtech ll, 46x32T, Chainguard

cassette

Shimano Cues CS-LG700, 11-45T

chain

KMC xGlide

Cockpit

headset

VP Integrated, Top 1 1/8", Bottom 1 1/2"

Stem

CUBE Performance Stem Pro, 31.8mm

handlebar

CUBE Comfort Trail Bar, 700mm

grips

ACID Travel Comfort

Wheels

rims

CUBE EX25, 32H, Disc, Tubeless Ready

front hub

Shimano HB-QC400, QR, Centerlock

tyres

Schwalbe Marathon Mondial, Kevlar, DD, 50-622

Finishing kit

saddle

ACID Sequence Pro 160

seat post

CUBE Performance Post, 27.2mm

pedals

CUBE PP MTB

Product information

colour

graphite´n´fossil

weight

13,4 kg

Art. No

860401

Because of ongoing problems in the delivery chain, the bike can be delivered with modifications.

More Information

Bike category of use: 2

You can find more information about Bike Classification at the following link.

More Information

140
kg

Maximum system weight

The system weight describes the maximum permissible total mass. This must not be exceeded under any circumstances.

Please see the table for information on the distribution of weight across the system in conjunction with compatible accessories (luggage carriers, bike trailers, etc.).

System weight table

Geometry

	46 cm	50 cm	54 cm
Seat tube	460	500	540
Top Tube Horizontal	570	580	595
Seat angle	74.5°	74°	73.5°
Head tube angle	70.5°	71°	71°
Chainstays	470	470	470
Head tube	130	140	160
Wheelbase	1107	1106	1116
BB-Height to Hub	60	60	60
Protrusion height - 80mm	684	696	716
Reach	398	399	403
Stack	619	630	649

Ergonomics

	46 cm	50 cm	54 cm
Stem length	90	90	90
Angle stem	17°	17°	17°
Handlebar width	700	700	700
Crank length	170	170	175
Length seat post	350	350	350
Diameter seatpost	27.2	27.2	27.2
Diameter tire maximum	742	742	742
Width tire maximum	50	50	50

All values are given in millimetres or degrees.

A great bike should let you explore without getting in the way. That's why, with the Nature SLX, we started with a lightweight aluminium frame and added an easily adjustable air-sprung Suntour fork, so even longer riders are comfortable. Then we added Shimano Cues 2x11 gears, whose wide range and easy shifting help you tackle any route. Matching Shimano Cues hydraulic disc brakes and grippy 50mm Schwalbe Marathon Mondial tyres give you the power you need to control your speed and come safely to a stop whenever you need to, even in wet weather. And unobtrusive mounting points for mudguards and a luggage carrier make it simple to expand your bike's versatility.
