NULANE C:62
SLT

SRP* 28790 NOK

ArtNo. 156500

greensmoothie´n´green

Comparison

LIGHTWEIGHT
ALL-ROUNDER

Based on our experience building fast, comfortable road and gravel bikes, the Nulane C:62's frame takes our high-quality C:62® carbon and transforms it into a light, lively and versatile chassis. But this is no featherweight carbon prima donna. We included ample clearance for 45mm tyres. The matching C:62® carbon fork continues the light, comfortable and versatile theme with lowrider rack mounts. Set it up your way.

Frame Material

C:62®

Tire clearance

50mm

Highlights

There's more to the Nulane C:62 SLT than great looks. Carbon is surprisingly good at absorbing high-frequency vibration, making long days in the saddle more comfortable. So, with high-end components this is the ideal all-rounder for town and country.

The Nulane C:62 SLT combines the low weight and comfort of a full C:62® carbon frame and fork with slick, reliable components. Sram's Apex Rival AXS 1x13 gears put a huge range of closely-spaced, hill-devouring ratios at your fingertips. Powerful, progressive Magura MT4 hydraulic disc brakes ensure you're always in full control of your speed. There's a light, dependable Newmen Performance Gravel 25 wheelset with grippy 45mm Schwalbe G-One Allround tyres. And with loads of tyre clearance and a full set of mounts front and rear for rack and mudguards, it's easy to set up as a bespoke commuter or tourer, too. Gravel or tarmac, city or countryside... it's your choice.

Frame

frame

C:62® Advanced Twin Mold, Internal Cable Routing, Flat Mount Disc, Fender/Rack & Kickstand Option, 12x142mm, AXH

Not all carbon is created equal. With our C:62® carbon we increased the high modulus fibre content, then we reinforced the resulting material with nanoparticles incorporated into the bonding resin. Which is all just a fancy way of saying it's extremely strong, light and durable.

Cables connect your handlebar controls to vital components like gears and brakes, but there's no need for them to get in your way. With Internal Cable Routing we've reduced clutter and maintenance by running cables through the frame, keeping them out of the way of dust and water contamination – or damage from abrasion – as well as cleaning up your bike's appearance.

Combining everything we know about building great-riding off-road bikes, Gravel Comfort Geometry is the secret ingredient that makes our gravel series such a blast to ride. Nimble enough to mix it up in the rough, stable enough for reassuring descents and with comfort for the long haul, we've got it all covered.

With our Advanced Twin Mold process we use two precisely manufactured forms for our C:62®, C:68® and C:68X® carbon frames. The first form is to ensure an accurate layup. The second, inner form keeps every individual fibre precisely where it needs to be while the frame cures. The result is a significantly lighter, stronger frame, with fibre density tailored to anticipated loadings at specific points.

size

Classic: 50cm, 53cm, 56cm, 59cm, 61cm

fork

CUBE TS Disc, Full Carbon, Taper, Flat Mount, 12x100mm

Drivetrain & brakes

brake system

Magura MT4, Flat Mount, Hydr. Disc Brake (160/160)

rear derailleur

Sram Rival XPLR AXS E1, 13-Speed

shifters

Sram AXS™ Pod Ultimate Controller

bottom bracket

Sram DUB Road Wide, Pressfit

crankset

Sram Rival E1 XPLR, DUB Wide, 40T

cassette

SRAM XPLR XG-1351, 10-46T

Cockpit

Stem

Newmen Evolution SL 318.4, 31.8mm

handlebar

CUBE Flat Race Bar, 660mm

grips

ACID Travel

Wheels

wheelset

Newmen Performance X.R.25, 28/28 Spokes, 12x100mm / 12x142mm, Tubeless Ready

tyres

Schwalbe G-One Allround, Kevlar, 45-622

Finishing kit

saddle

ACID Nuance Pro

seat post

Newmen Advanced, Carbon, 27.2mm

Product information

colour

greensmoothie´n´green

weight

8,8 kg

Art. No

156500

SRP*

28790 NOK

*Suggested retail price

Due to unforeseeable supply chain issues, the bike may be delivered with modifications.

More Information

Bike category of use: 2

You can find more information about Bike Classification at the following link.

More Information

100
kg

Maximum rider weight

The rider weight refers to the weight of the rider including clothing and any equipment worn on the body.

Please see the table for information on the distribution of weight across the system in conjunction with compatible accessories (luggage carriers, bike trailers, etc.).

System weight table

Geometry

	50 cm	53 cm	56 cm	58 cm	61 cm
Seat tube	430	460	490	510	540
Top Tube Horizontal	522	537	560	575	592
Seat angle	75.5°	74.7°	73.9°	73°	73°
Head tube angle	69°	70°	71.5°	72°	72.5°
Chainstays	440	440	440	442	442
Head tube	102	124	155	174	197
Wheelbase	1043	1044	1046	1048	1060
BB-Height to Hub	70	70	70	70	70
Protrusion height - 80mm	743	771	805	824	851
Reach	388	388	393	392	402
Stack	520	544	579	599	623

Ergonomics

	50 cm	53 cm	56 cm	58 cm	61 cm
Stem length	70	70	90	90	90
Angle stem	6°	6°	6°	6°	6°
Handlebar width	660	660	660	660	660
Length seat post	350	350	400	400	400
Diameter seatpost	27.2	27.2	27.2	27.2	27.2
Diameter tire maximum	728	728	728	728	728
Width tire maximum	50	50	50	50	50
