A lighter bike is one that's better to ride. That's the reason for the Nature's double-butted aluminium tubes, which reduce weight without sacrificing strength or durability. Clearance for tyres up to 50mm wide allows for a more comfortable ride and a tapered head tube ensures precise steering. Sleek luggage carrier and mudguard mounting points and Smooth Welding frame joints complement the frame's good looks and make it easy to upgrade to suit your needs. You can rest assured that, as with all our frames, the Nature has passed all our stringent in-house safety tests. It's in it for the long haul.
Frame Material

Frame
frame
Aluminium Superlite, Trekking Cross, Taper, Double Butted
size
Classic: XS / 46cm, S / 50cm, M / 54cm, L / 58cm, XL / 62cm
Suspension
Suspension fork
SR Suntour NCX E RL Air T, 63mm, Remote Lockout
Drivetrain & brakes
brake system
Shimano Cues BR-U8000, Hydr. Disc Brake (180/160)
rear derailleur
Shimano Cues RD-U8020-SGS, 11-Speed
shifters
Shimano Cues SL-U8000-I, Direct Attach, Rapidfire-Plus
front derailleur
Shimano Cues FD-U8010, Top Swing, 31.8mm
bottom bracket
Shimano BB-MT501, 68mm BSA
crankset
Shimano Cues FC-U8000, Hollowtech ll, 46x32T, Chainguard
cassette
Shimano Cues CS-LG700, 11-45T
chain
KMC xGlide
Cockpit
headset
VP Integrated, Top 1 1/8", Bottom 1 1/2"
Stem
CUBE Performance Stem Pro, 31.8mm
handlebar
CUBE Comfort Trail Bar, 700mm
grips
ACID Travel Comfort
Wheels
rims
CUBE EX25, 32H, Disc, Tubeless Ready
front hub
Shimano HB-QC400, QR, Centerlock
tyres
Schwalbe Marathon Mondial, Kevlar, DD, 50-622
Finishing kit
saddle
ACID Sequence Pro 160
seat post
CUBE Performance Post, 27.2mm
pedals
CUBE PP MTB
Product information
colour
graphite´n´fossil
weight
13,4 kg
Art. No
860400
Because of ongoing problems in the delivery chain, the bike can be delivered with modifications.
More Information
Bike category of use: 2
You can find more information about Bike Classification at the following link.
140
kg
Maximum system weight
The system weight describes the maximum permissible total mass. This must not be exceeded under any circumstances.
Please see the table for information on the distribution of weight across the system in conjunction with compatible accessories (luggage carriers, bike trailers, etc.).
Geometry
46 cm | 50 cm | 54 cm | 58 cm | 62 cm | |
Seat tube | 440 | 480 | 520 | 560 | 600 |
Top Tube Horizontal | 570 | 585 | 600 | 615 | 622 |
Seat angle | 74.5° | 73.5° | 73° | 73° | 73° |
Head tube angle | 70.5° | 71° | 71° | 71° | 71° |
Chainstays | 470 | 470 | 470 | 470 | 470 |
Head tube | 105 | 120 | 140 | 155 | 170 |
Wheelbase | 1105 | 1104 | 1114 | 1130 | 1137 |
BB-Height to Hub | 60 | 60 | 60 | 60 | 60 |
Protrusion height - 80mm | 772 | 805 | 838 | 867 | 897 |
Reach | 405 | 404 | 407 | 418 | 421 |
Stack | 595 | 612 | 630 | 645 | 659 |
Ergonomics
46 cm | 50 cm | 54 cm | 58 cm | 62 cm | |
Stem length | 90 | 90 | 90 | 90 | 90 |
Angle stem | 6° | 6° | 6° | 6° | 6° |
Handlebar width | 700 | 700 | 700 | 700 | 700 |
Crank length | 170 | 170 | 175 | 175 | 175 |
Length seat post | 350 | 350 | 350 | 350 | 350 |
Diameter seatpost | 27.2 | 27.2 | 27.2 | 27.2 | 27.2 |
Diameter tire maximum | 742 | 742 | 742 | 742 | 742 |
Width tire maximum | 50 | 50 | 50 | 50 | 50 |
All values are given in millimetres or degrees.
