With the Aim Allroad we're redefining versatility. The included full-length mudguards, luggage carrier and lighting system mean it has everything you need right out of the box. There's a threaded bottom bracket and internal cable routing for long-lasting service and simple maintenance, the tapered head tube helps improve handling, and the flat disc mount integrates seamlessly with the included kickstand. Carefully thought out geometry includes a lower top tube for more confident handling, and there's plenty of room to run wide, grippy and comfortable 2.25in tyres. Our Size Split system has an expanded range, too, so however tall you are there'll be an Aim Allroad that fits perfectly.

Frame Material

Aluminium Lite

Sizes

Size Split

Configuration

Allroad
Have your cake and eat it, with the Aim SLX Allroad. Fully equipped for off-road adventuring, we also fitted a full range of accessories so it's just as adept at whisking you across town. From countryside adventures at the weekend to shopping expeditions or the daily commute, it's all you need in a single bike.
  1.
  2.
  3.
  4.
  5.
AIM
There's aluminium, and then there's CUBE Aluminium Lite. This heat-treated 6061 aluminium is stiff, fatigue-resistant and, because of its natural corrosion resistance, a great material from which to make lightweight tube sets – and bicycle frames. And it does all this without adding unnecessary weight, so you can get the best enjoyment out of your CUBE.
The right bike should fit you perfectly. That's why we created SizeSplit. For shorter riders, the smaller 27.5in wheel standard allows us to build frames that fit well while remaining agile and sure-footed. And, for taller riders, we built a range of sizes around the fast-rolling 29er wheel standard. Whichever one you choose, you can be sure of a fit that makes your bike feel as though it was built just for you.
How versatile is a bicycle? When it's a CUBE Allroad, the answer is 'extremely'. Boasting a full complement of accessories including (depending on model) luggage carrier, mudguards, lights and kickstand, we built your Allroad to take on anything you care to throw its way. Weekday commuting, weekend touring and everything in between... our Allroad series has it covered.
Cables connect your handlebar controls to vital components like gears and brakes, but there's no need for them to get in your way. With Internal Cable Routing we've reduced clutter and maintenance by running cables through the frame, keeping them out of the way of dust and water contamination – or damage from abrasion – as well as cleaning up your bike's appearance.
Smooth Welding isn't easy, but worthwhile things usually aren't. It has two advantages. First, and most obviously, it looks great: one tube seems to almost flow into the other. Second, and at least as importantly, it helps to minimise load peaks on welded areas for better frame strength and durability.

Frame

frame

Aluminium Lite, AMF, Double Butted, Internal Cable Routing, Tapered Head Tube, Flat Mount Brake, SIC Mount, FM Kickstand Mount

size

Size Split: 27.5: XS, S // 29: M, L, XL, XXL

Suspension

Suspension fork

SR Suntour XCM Disc, 100mm, Remote Lockout

Drivetrain & brakes

brake system

Shimano BR-MT200/UR300, Hydr, Disc Brake, PM/FM (160/160)

rear derailleur

Shimano Cues RD-U6000-GS, 11-Speed

shifters

Shimano Cues SL-U6000, Rapidfire Plus

bottom bracket

Thun Paso-ML, 73mm BSA

crankset

Prowheel CC10Y-NW, 32T, 170mm

cassette

Shimano Cues CS-LG400, 11-50T

chain

KMC xGlide

Cockpit

headset

CUBE FPH868, Semi-Integrated

Stem

CUBE Performance Stem, 31.8mm

handlebar

CUBE Rise Trail Bar, 680mm

grips

ACID Icon

Wheels

rims

CUBE EX25, 32H, Disc, Tubeless Ready

front hub

Shimano DH-3D37, Hub Dynamo, QR, Centerlock

rear hub

Shimano FH-QC300-HM, QR, Centerlock

tyres

Schwalbe Smart Sam, Active, 2.25

Finishing kit

saddle

ACID Venec Lite

seat post

CUBE Performance Post, 27.2mm

pedals

CUBE PP MTB

front light

CUBE Shiny 50

rear light

ACID Mudguard Rear Light PRO-D, 6V, AC

kickstand

ACID FM Pure Kickstand

mudguards

ACID 65

bell

Easy Bell

carrier

ACID Semi-Integrated Carrier, ACID RILink Adapter Compatible and Rail

Product information

colour

slateblack´n´black

weight

17,2 kg

Art. No

841270

Because of ongoing problems in the delivery chain, the bike can be delivered with modifications.

More Information

Bike category of use: 2

You can find more information about Bike Classification at the following link.

140
kg

Maximum system weight

The system weight describes the maximum permissible total mass. This must not be exceeded under any circumstances.

Please see the table for information on the distribution of weight across the system in conjunction with compatible accessories (luggage carriers, bike trailers, etc.).

Geometry

XS S M L XL XXL
Seat tube 340 370 420 470 515 560
Top Tube Horizontal 555 575 595 615 635 655
Seat angle 74° 73.5° 73.5° 73.5° 73.5° 73.5°
Head tube angle 68.5° 68.5° 68.5° 68.5° 68.5° 68.5°
Chainstays 427 427 450 450 450 450
Head tube 108 111 111 122 142 157
Wheelbase 1068 1082 1125 1146 1168 1190
BB-Height to Hub 52 52 65 65 65 65
Protrusion height - 80mm 707 720 759 792 824 858
Reach 384 398 409 426 441 457
Stack 595 598 627 637 656 670
Stack Reach BB-Height to Hub Wheelbase Head tube Chainstays Head tube angle Seat angle Top Tube Horizontal Seat tube Protrusion height - 80mm

Ergonomics

XS S M L XL XXL
Stem length 50 50 60 60 70 70
Angle stem
Handlebar width 680 680 720 720 720 720
Crank length 165 170 170 175 175 175
Length seat post 350 350 400 400 400 400
Diameter seatpost 27.2 27.2 27.2 27.2 27.2 27.2
Diameter tire maximum 708 708 747 747 747 747
Width tire maximum 57 57 57 57 57 57

All values are given in millimetres or degrees.

Mountain bikes remove barriers. It's in that spirit that we made our Aim SLX Allroad as adaptable as we possibly could. Mudguards, a lighting system, kickstand and versatile luggage carrier give you the tools you need to take on the weekday commute or a dash across town. Meanwhile the 100mm suspension fork, Shimano Cues 1x11 gears, hydraulic disc brakes and grippy 2.25in tyres are all you need to keep on riding when the tarmac ends. And our Size Split system means there's a perfectly proportioned Aim SLX Allroad for every rider. You really can have your cake and eat it...
