REACTION HYBRID
ONE 800

SRP* 3189 EUR

ArtNo. 808151

silver´n´black

Comparison

600Wh

ADVENTURE
ON!

It's looks are familiar, but the Reaction Hybrid's design details set it apart. With the 800 Wh PowerTube battery neatly concealed and the Bosch CX drive housed securely, its svelte lines disguise lots of clever features. It's PowerMore-ready, making it easy to add up to 250 Wh of extra battery capacity. The integrated seat clamp and cable routing complement the clean aesthetic, whilst a UDH gear hanger makes it as future-proof as possible. There's a built-in chainguide mount too, and it's also ready to accept ACID mudguards. And, with Size Split, it's easy to find the perfect fit for every rider. We've thought of everything, so you can just ride.

Frame Material

Aluminium Superlite

Battery

800 Wh

Sizes

Size Split

(Almost) no limits: with its 800 Wh battery, powerful and quiet Bosch motor and cunning CUBE frame design, the Reaction Hybrid ONE 800 is the go-anywhere mountain bike to take on any ride. Across town, into the countryside or over the hills and far away, let your curiosity guide you.

More Information

Bike category of use: 2

You can find more information about Bike Classification at the following link.

More Information

110
kg

Maximum rider weight

The rider weight refers to the weight of the rider including clothing and any equipment worn on the body.

Please see the table for information on the distribution of weight across the system in conjunction with compatible accessories (luggage carriers, bike trailers, etc.).

System weight table

Geometry

	S	M	L	XL
Seat tube	370	405	450	495
Top Tube Horizontal	587	607	627	647
Seat angle	74.5°	74°	74°	74°
Head tube angle	67.5°	67.5°	67.5°	67.5°
Chainstays	456	470	470	470
Head tube	159	110	120	130
Wheelbase	1157	1176	1197	1216
BB-Height to Hub	46	65	65	65
Protrusion height - 80mm	688	721	721	724
Reach	409	420	437	455
Stack	643	653	662	671

Ergonomics

	S	M	L	XL
Stem length	60	60	60	60
Angle stem	12°	12°	12°	12°
Handlebar width	740	740	740	740
Crank length	165	175	175	175
Length seat post	350	400	400	400
Diameter seatpost	31.6	31.6	31.6	31.6
max. zasunutí sedlovky	205	250	280	300
Stroke seatpost	100	100	130	130
Diameter tire maximum	722	760	760	760
Width tire maximum	66	66	66	66

All values are given in millimetres or degrees.

If you've ever wondered where that path you've never ridden goes, we have the bike with which to find out. With its high-capacity 800 Wh battery and quiet, powerful Bosch motor, the Reaction Hybrid ONE 800 gives you the freedom to explore. Smooth-shifting Shimano Cues 10-speed gears help make light work of any route – even hilly ones. To make life on the trail – and city streets – a little more comfortable, we fitted a suspension fork with 120mm of travel (100mm for small frame sizes and for all Easy Entry models). And, to help keep you safe, there's a set of powerful hydraulic disc brakes that are designed to bring you safely to a stop, no matter the conditions.
