NUROAD C:62
SLT

SRP* 6099 EUR

ArtNo. 830600

Comparison

LIGHTWEIGHT
TOUGHNESS

The Nuroad C:62 frame takes everything we know about carbon gravel frames and takes it up a notch. We increased tyre clearance up to 50mm. There's an integrated seat clamp and semi-integrated cable routing to complement the frame's elegant, organic appearance. It's UDH-ready, for versatility and future-proofing. The C:62® carbon fork has two carrier mounting positions. And the frame weight for all this practical innovation? Just 1,150g for a mid-sized frame. So it's tough, but also extremely light. That's versatility, redefined for a new era of gravel exploration.

Frame Material

C:62®

Tire clearance

50 mm

Gravel riding with zero compromise: the Nuroad C:62 SLT sets the standard for lightweight, versatile and tough performance. With a frame featuring premium C:62® construction and the best components we could lay our hands on, it's the ideal blend of pace, comfort and adaptability.

NUROAD C:62

Not all carbon is created equal. With our C:62® carbon we increased the high modulus fibre content, then we reinforced the resulting material with nanoparticles incorporated into the bonding resin. Which is all just a fancy way of saying it's extremely strong, light and durable.

Gear and brake cables need a way to get from handlebar controls to frame – but what if there was no need for holes near the head tube? We came up with a design that takes cables into the frame via the headset, maintaining full internal cable routing but making it even neater and less obtrusive.

Our Integrated Seatpost Clamp is all part of our quest to sweat the details, so that you can reap the rewards. Its minimalist design suits the frame's pared-back aesthetic. And, of course, that's important – because why wouldn't you want your bike to look great? But it also saves a few grammes too. And that matters just as much...

Adventure sometimes demands different kit. That's where our low rider rack mounts come in. Designed to accept an optional fork rack, they're a great way to carry up to 10kg of additional weight for extended tours. Not only that but carrying some of your luggage over the front wheel helps improve weight distribution and handling. Win, win.

For gravel epics – or races – into the back country and beyond, our Gravel Endurance Geometry is designed with you in mind. With a ride position optimised for long days in the saddle and frame angles and dimensions geared towards the perfect balance of agility and stability, it's all you need for off-road adventure.

With our Advanced Twin Mold process we use two precisely manufactured forms for our C:62®, C:68® and C:68X® carbon frames. The first form is to ensure an accurate layup. The second, inner form keeps every individual fibre precisely where it needs to be while the frame cures. The result is a significantly lighter, stronger frame, with fibre density tailored to anticipated loadings at specific points.

Because the Nuroad C:62 is built for adventure, we added a third bottle cage mount under the down tube. Use it for carrying tools and a spare inner tube, or carry another water bottle – the choice is yours. Either way, you're all set for extended exploring.

Rough roads and tracks shake everything up. To keep everything where it should be and avoid the hassle of a dropped chain, we fitted the Nuroad C:62 with a chain guide for a 1x transmission. Because it's purpose-designed for the job, there's almost no way to shake the chain off the chainring... so you can concentrate on the riding.

Frame

frame

C:62® Advanced Twin Mold Technology, Internal Cable Routing, Integrated Seat Post Clamp, Flat Mount Disc, Kickstand Option, 12x142mm, UDH™

size

XS (50cm), S (53cm), M (56cm), L (58cm), XL (61cm)

Rigid fork

CUBE C:62® Technology, 1 1/8" - 1 1/2" Tapered, Integrated Cable Routing, Flat Mount Disc, Fender & Lowrider Mounts, Internal Light Cable Option, 12x100mm

Drivetrain & brakes

shift/ brake levers

Sram Red AXS™

brake system

Sram Red AXS™, Hydr. Disc Brake (160/160)

rear derailleur

Sram Red XPLR AXS™, 13-Speed, Electronic Shifting System

bottom bracket

Sram DUB Road Wide, Pressfit

crankset

Sram Red XPLR Power Meter, Carbon, 40T

cassette

Sram Red XPLR XG-1391, 10-46

chain

Sram Red E1

Cockpit

headset

ACROS, Top Integrated 1 1/2" w/ Integrated Cable Routing, Bottom Integrated 1 1/2"

Stem

CUBE CIS Stem w/ Cable Routing

handlebar

Newmen Advanced Gravel Bar 318, Carbon, 31.8mm

handlebar tape

ACID Bartape CX

Wheels

wheelset

Newmen Advanced SL X.R.36 VONOA Carbon, 21/21 Carbon Spokes, 12x100mm/12x142mm, Tubeless Ready

tyres

Schwalbe G-One-R, Kevlar, 40-622

rear tyre

Schwalbe G-One-RS, Kevlar, 40-622

Finishing kit

saddle

ACID Nuance SLT X Carbon

seat post

Newmen Advanced, Carbon, 27.2mm

extras

ACID Pack Pro 0,7 Top Tube Bag

Product information

colour

mineralgrit´n´black

weight

7,5 kg

Art. No

830600

SRP*

6099 EUR

*Suggested retail price

Because of ongoing problems in the delivery chain, the bike can be delivered with modifications.

More Information

Bike category of use: 2

You can find more information about Bike Classification at the following link.

More Information

130
kg

Maximum system weight

The system weight describes the maximum permissible total mass. This must not be exceeded under any circumstances.

Please see the table for information on the distribution of weight across the system in conjunction with compatible accessories (luggage carriers, bike trailers, etc.).

System weight table

Geometry

	XS	S	M	L	XL
Seat tube	430	460	490	510	540
Top Tube Horizontal	522	537	560	575	592
Seat angle	75.5°	74.7°	73.9°	73°	73°
Head tube angle	69°	70°	71.5°	72°	72.5°
Chainstays	440	440	440	442	442
Head tube	102	124	155	174	197
Wheelbase	1043	1044	1046	1048	1060
BB-Height to Hub	70	70	70	70	70
Protrusion height - 80mm	743	771	805	824	851
Reach	388	388	393	392	402
Stack	520	544	579	599	623

Ergonomics

	XS	S	M	L	XL
Stem length	80	80	90	100	100
Handlebar width	420	440	440	460	460
Crank length	170	170	172.5	172.5	175
Length seat post	350	350	350	400	400
Diameter seatpost	27.2	27.2	27.2	27.2	27.2
Diameter tire maximum	728	728	728	728	728
Width tire maximum	50	50	50	50	50

All values are given in millimetres or degrees.

Gravel routes can be tough on bike and body, but the Nuroad C:62 SLT is more than up to the task. The vibration-absorbing comfort of the lightweight C:62® carbon frame and fork is complemented by grippy, fast-rolling 40mm Schwalbe G-One R and RS tyres and Aerothan tubes rolling on Newmen Advanced SL X.R.36 Vonoa wheels with carbon rims and spokes. Powerful Sram Red AXS hydraulic disc brakes ensure you can always slow and stop safely, whatever the conditions. And Sram's Red XPLR AXS puts a huge 1x13 range of gears at your fingertips with precise electronic control and a built-in power meter. Ride far, ride light, ride wherever you like.
