COMMUTE.
TRAIN.
EXPLORE.
Versatile can be fast, and fast can be versatile, too. That's why, with the Nulane frame, we added mounting points for easy mudguard and carrier upgrades. There are even lowrider rack points on the full carbon fork, so it's practical as well as comfortable. Superlite double-butted aluminium frame tubes keep the weight down. We added flat mount disc attachment points for sleek looks and the best stopping performance. And finished off with thru axles front and rear to ensure safe and predictable handling, laden or unladen.
Frame Material

Frame
frame
Aluminium Superlite Trekking Sport, Flat Mount Disc, 12x142mm, AXH
size
Classic: 50cm, 53cm, 56cm, 59cm, 62cm
Rigid fork
CUBE TS Disc, Full Carbon, Taper, Flat Mount, 12x100mm
Drivetrain & brakes
brake system
Tektro HD-R280, Hydr. Disc, Flat Mount (160/160)
rear derailleur
Shimano Cues RD-U4000-GS, 9-Speed
shifters
Shimano Cues SL-U4010- Rapidfire-Plus
bottom bracket
Shimano BB-MT500PA, 92mm Pressfit
crankset
ACID Gravel Pro, 40T
cassette
Shimano Cues CS-LG300, 11-46T
chain
KMC xGlide
Cockpit
headset
VP Semi-Integrated, 1 1/8", Bottom Integrated, 1 1/4"
Stem
CUBE Performance Stem Pro, 31.8mm
handlebar
CUBE Flat Race Bar, 660mm
grips
ACID Travel
Wheels
wheelset
CUBE OR 2.5 Disc, Tubeless Ready
tyres
Schwalbe G-One Allround, Kevlar, 40-622
Finishing kit
saddle
ACID Nuance Lite
seat post
CUBE Performance Post, 27.2mm
pedals
CUBE PP MTB
Product information
colour
mineralgrey´n´black
weight
10,3 kg
Art. No
856100
SRP*
819 EUR
*Suggested retail price
Because of ongoing problems in the delivery chain, the bike can be delivered with modifications.
More Information
Bike category of use: 2
You can find more information about Bike Classification at the following link.
115
kg
Maximum system weight
The system weight describes the maximum permissible total mass. This must not be exceeded under any circumstances.
Please see the table for information on the distribution of weight across the system in conjunction with compatible accessories (luggage carriers, bike trailers, etc.).
Geometry
50 cm | 53 cm | 56 cm | 59 cm | 62 cm | |
Seat tube | 460 | 490 | 520 | 550 | 580 |
Top Tube Horizontal | 542 | 566 | 574 | 593 | 612 |
Seat angle | 74° | 73° | 73° | 73° | 73° |
Head tube angle | 70.5° | 71.5° | 72° | 72° | 72° |
Chainstays | 442 | 442 | 442 | 442 | 442 |
Head tube | 137 | 157 | 172 | 197 | 227 |
Wheelbase | 1044 | 1049 | 1052 | 1072 | 1091 |
BB-Height to Hub | 60 | 60 | 60 | 60 | 60 |
Protrusion height - 80mm | 753 | 780 | 804 | 831 | 860 |
Reach | 385 | 391 | 395 | 406 | 416 |
Stack | 548 | 571 | 587 | 611 | 640 |
Ergonomics
50 cm | 53 cm | 56 cm | 59 cm | 62 cm | |
Stem length | 90 | 90 | 90 | 90 | 90 |
Angle stem | 6° | 6° | 6° | 6° | 6° |
Handlebar width | 660 | 660 | 660 | 660 | 660 |
Crank length | 170 | 170 | 170 | 175 | 175 |
Length seat post | 350 | 350 | 350 | 350 | 350 |
Diameter seatpost | 27.2 | 27.2 | 27.2 | 27.2 | 27.2 |
Diameter tire maximum | 711 | 711 | 711 | 711 | 711 |
Width tire maximum | 42 | 42 | 42 | 42 | 42 |
All values are given in millimetres or degrees.
