Want to get more out of the places you ride? The Reaction Hybrid Pro's powerful Bosch CX motor, sleek frame design and reliable components will get you there and back again in comfort and style. With an Easy Entry frame option and sizes right down to S with no compromise on battery capacity, there's one to suit everyone.

More Information

Bike category of use: 3

You can find more information about Bike Classification at the following link.

More Information

150
kg

Maximum system weight

The maximum system weight corresponds to the maximum combined weight of the rider and bike. Please refer to the table for information on the distribution of weight across the system in conjunction with compatible mounted parts (luggage carriers etc.).

System weight table

Geometry

Slack/Moderate	15" / 27.5 / S	17" / 29 / M	19" / 29 / L	21" / 29 / XL	23" / 29 / XXL
Seat tube	380	405	450	495	545
Top Tube Horizontal	565	628	628	645	672
Seat angle	75°	74°	74°	74°	74°
Head tube angle	67°	67.5°	67.5°	68°	68°
Chainstays	447	460	460	460	460
Head tube	120	122	122	132	149
Wheelbase	1135	1196	1196	1208	1236
BB-Height to Hub	45	65	65	65	65
Protrusion height - 80mm	756	762	768	781	821
Reach	400	444	442	456	478
Stack	614	646	651	662	678

Ergonomics

	15" / 27.5 / S	17" / 29 / M	19" / 29 / L	21" / 29 / XL	23" / 29 / XXL
Length seat post	350	350	350	400	400
Diameter seatpost	30.9	30.9	30.9	30.9	30.9
Angle stem	12°	12°	12°	12°	12°
Crank length	175	175	175	175	175
Diameter tire maximum	720	762	762	762	762
Width tire maximum	68	68	68	68	68
Stem length	60	40	50	60	60
Handlebar width	740	740	740	740	740
