Trocha pozornosti navyše venovanej detailom môže znamenať veľa. S odpruženou prednou vidlicou RockShox vám Aim SLX ponúka istotu a extra kontrolu a komfort, ktoré potrebujete, aby ste pri objavovaní mohli zájsť ešte o kúsok ďalej. Pokračujte... objavte svoje dobrodružné ja...

More Information

Bike category of use: 3

You can find more information about Bike Classification at the following link.

More Information

115
kg

Maximálna hmotnosť bicykla a jazdca

The weight refers to the combined weight of the rider and bike including all clothing and equipment carried on the rider's person (backpacks etc.) and must not be exceeded.

150
kg

Maximum system weight

The maximum system weight refers to the combined weight of the rider and bike (which is subject to a separate weight limit that must not be exceeded) plus any accessories attached to the bike, such as a trailer, luggage carrier, etc.

Further details can be found in the system weight table.

System weight table

Geometry

	14" / 27.5 / XS	16" / 27.5 / S	18" / 29 / M	20" / 29 / L	22" / 29 / XL	24" / 29 / XXL
Seat tube	340	370	420	470	515	560
Top Tube Horizontal	555	575	595	615	635	655
Seat angle	74°	73.5°	73.5°	73.5°	73.5°	73.5°
Head tube angle	68.5°	68.5°	68.5°	68.5°	68.5°	68.5°
Chainstays	427	427	450	450	450	450
Head tube	108	111	111	122	142	157
Wheelbase	1068	1082	1125	1146	1168	1190
BB-Height to Hub	52	52	65	65	65	65
Protrusion height - 80mm	707	720	759	792	824	858
Reach	384	398	409	426	441	457
Stack	595	598	627	637	656	670

Ergonomics

	14" / 27.5 / XS	16" / 27.5 / S	18" / 29 / M	20" / 29 / L	22" / 29 / XL	24" / 29 / XXL
Length seat post	350	350	400	400	400	400
Diameter seatpost	27.2	27.2	27.2	27.2	27.2	27.2
Angle stem	6°	6°	6°	6°	6°	6°
Crank length	170	170	170	170	170	170
Diameter tire maximum	708	708	747	747	747	747
Width tire maximum	57	57	57	57	57	57
Stem length	45	45	60	60	75	75
Handlebar width	680	680	680	680	680	680
