The Acid 200's heat-treated, 6061 aluminium frame has the same quality and durability as our full-size mountain bikes. It's light and strong, thanks to a curved and formed down tube that's tailored specifically to a young rider's weight. V-brake bosses front and rear are just the same as you'll find on mum or dad's bike. And, because we know that accidents can happen, we fitted a replaceable derailleur hanger – so that an unexpected tumble doesn't write off the frame.
Frame Material
Wheels
More Information
Bike category of use: 0
You can find more information about Bike Classification at the following link.
40
kg
Maximum system weight
The maximum system weight corresponds to the maximum combined weight of the rider and bike. Please refer to the table for information on the distribution of weight across the system in conjunction with compatible mounted parts (luggage carriers etc.).
This children's bike is a OneSize model suitable for kids up to the following maximum measurements:
HEIGHT: 111 - 124 cm
INSEAM: 49 - 57 cm
Please note this information is only a general recommendation. It cannot replace a personal consultation and test ride with a CUBE dealer.
Geometry
| Slack/Moderate | 20" |
|---|---|
| Seat tube | 258 |
| Top Tube Horizontal | 438 |
| Seat angle | 73.5° |
| Head tube angle | 72° |
| Chainstays | 374 |
| Head tube | 105 |
| Wheelbase | 854 |
| BB-Height to Hub | 20 |
| Protrusion height - 80mm | 529 |
| Reach | 327 |
| Stack | 417 |
All values are given in millimetres or degrees.
Frame Parts
Mudguards
ACID Mudguard Set MUD ROOKIE 18" / 20"
Kickstands
CUBE Kickstand Kid Bikes
