De Supreme Hybrid ONE is een echte allemansvriend die perfect past in jouw leven. Z'n soepele Bosch-trapondersteuning, z'n lage instap en z'n stabiele rijeigenschappen maken zelfs het kortste ritje tot een feest. Naar je werk, naar de bakker of een avondje stappen: deze e-bike is erbij.

More Information

Bike category of use: 2

You can find more information about Bike Classification at the following link.

More Information

135
kg

Maximaal gewicht van fiets en fietser

The weight refers to the combined weight of the rider and bike including all clothing and equipment carried on the rider's person (backpacks etc.) and must not be exceeded.

140
kg

Maximum system weight

The maximum system weight refers to the combined weight of the rider and bike (which is subject to a separate weight limit that must not be exceeded) plus any accessories attached to the bike, such as a trailer, luggage carrier, etc.

Further details can be found in the system weight table.

System weight table

Geometry

Slack/Moderate	46 cm / XS	50 cm / S	54 cm / M	58 cm / L
Zitbuis	440	480	520	560
Top Tube Horizontal	605	605	617	629
Seat angle	73.5°	73.5°	73.5°	73.5°
Head tube angle	70°	70°	70°	70°
Kettingsteunen	499	499	499	499
Balhoofdbuis	195	195	210	230
Wielbasis	1143	1143	1156	1169
BB-Height to Hub	70	70	70	70
Projectie hoogte - 80mm	427	427	427	427
Reach	387	387	394	401
Stack	669	669	684	702

Ergonomics

	46 cm / XS	50 cm / S	54 cm / M	58 cm / L
Zadelpen lengte	350	350	350	350
Diameter zadelpen	30.9	30.9	30.9	30.9
Crank lengte	165	165	165	165
Maximale banddiameter	736	736	736	736
Maximale bandbreedte	50	50	50	50
Lengte van de stam	65	90	90	90
Stuurbreedte	660	660	660	660
