TOURING
ONE

SRP* 839 EUR

ArtNo. 862102

Comparison

WHATEVER.
WHEREVER.

The heart of the Touring is its high-quality, low-weight, double-butted aluminium frame. We designed the Easy Entry frame to do exactly what it says, making mounting and dismounting a breeze. Designed with our Efficient Comfort Geometry to make light work of even long days in the saddle, it'll surprise you with its nimble and intuitive handling. With gear cables routed inside the down tube for long-lasting accurate gear shifts with minimal maintenance, you can just enjoy the ride. Our neat semi-integrated luggage carrier means you can take whatever you need for the journey, and the Flat Mount kickstand makes parking your bike a cinch.

Frame Material

Aluminium Superlite

When you're out exploring you want a bike that's comfortable. So we designed the Touring ONE's frame with our Efficient Comfort Geometry, which does exactly what it says, whichever frame style you choose. With a full complement of practical accessories, including luggage carrier, mudguards, kickstand and lights, it's all you need for new adventures.

TOURING

Our trekking series is designed to take you wherever your curiosity leads you. So, of course, you'll want a comfortable ride. With a natural feeling seated position and handling that's stable and reassuring with or without a load, Trekking Comfort Geometry does exactly what it says no matter how much experience you have of cycling.

Cables for your gears and brakes are essential, but you don't necessarily want to see them all the time. Our semi internal cable routing takes gear and brake cables through the down tube for a cleaner appearance, smoother shifts and reduced maintenance. So your CUBE bike looks good and continues to function as it should, and you just concentrate on enjoying the ride.

CUBE's Aluminium Superlite starts with heat-treated 6061 aluminium, which has the qualities – high fatigue resistance, good stiffness, low weight and excellent strength – that are important for a bicycle frame. Then we make it into double butted tubes, to reduce weight without sacrificing any of its strength. The result? Exceptionally light, strong and tough frames.

Frame

frame

Aluminium Superlite, Trekking Comfort, Double Butted

size

Easy Entry: XS / 45cm, S / 49cm, M / 53cm

Suspension

Suspension fork

SR Suntour NEX, 63mm

Drivetrain & brakes

brake system

Shimano BR-MT200/UR300, Hydr, Disc Brake, PM/FM (160/160)

rear derailleur

Shimano Essa RD-U2000-GS, 8-Speed

shifters

Shimano SL-M315, Rapidfire-Plus

bottom bracket

Thun Paso-ML, 68mm, BSA

crankset

Shimano Essa FC-U2000-1, 40T

cassette

Shimano CS-HG400, 11-45T

chain

KMC Z51

Cockpit

headset

CUBE H863, 1 1/8" , Semi-Integrated

Stem

CUBE Comfort Stem Pro, 31.8mm, Adjustable

handlebar

CUBE Comfort Trail Bar, 680mm

grips

ACID Travel Comfort

Wheels

rims

CUBE ZX20, 32H, Disc, Tubeless Ready

front hub

Shimano DH-3D37, Hub Dynamo, QR, Centerlock

rear hub

Shimano FH-QC300-HM, QR, Centerlock

tyres

CUBE Trekking, 47-622

Finishing kit

saddle

Natural Fit Sequence

seat post

CUBE Performance Post, 27.2mm

pedals

CUBE PP MTB

front light

CUBE Shiny 50

rear light

ACID Mudguard Rear Light PRO-D, 6V, AC

kickstand

ACID FM Pure Kickstand

mudguards

ACID 53 BB-Mount

bell

Nuvo

carrier

ACID Semi-Integrated Carrier, ACID RILink Adapter Compatible

Product information

colour

deepsea´n´blackchrome

weight

17,4 kg

Art. No

862102

SRP*

839 EUR

*Suggested retail price

Because of ongoing problems in the delivery chain, the bike can be delivered with modifications.

More Information

Bike category of use: 2

You can find more information about Bike Classification at the following link.

More Information

140
kg

Maximum system weight

The system weight describes the maximum permissible total mass. This must not be exceeded under any circumstances.

Please see the table for information on the distribution of weight across the system in conjunction with compatible accessories (luggage carriers, bike trailers, etc.).

System weight table

Geometry

	45 cm	49 cm	53 cm
Seat tube	460	500	540
Top Tube Horizontal	578	593	608
Seat angle	74°	73°	73°
Head tube angle	70°	70°	70°
Chainstays	455	455	455
Head tube	170	185	200
Wheelbase	1094	1098	1114
BB-Height to Hub	75	75	75
Reach	391	390	400
Stack	650	665	679

Ergonomics

	45 cm	49 cm	53 cm
Stem length	65	90	90
Handlebar width	680	680	680
Crank length	175	175	175
Length seat post	350	350	350
Diameter seatpost	27.2	27.2	27.2
Max. insertion depth seat post	300	300	300
Diameter tire maximum	728	728	728
Width tire maximum	47	47	47

All values are given in millimetres or degrees.

The Touring ONE's full equipment package and comfortable design is all you need to broaden your riding horizons. Easy-to-use 3x8 Shimano Essa gears make light work of any route by putting gear selection literally at your fingertips. Powerful disc brakes work better than standard brakes in the wet, for safer stopping. A suspension fork and 47mm-wide tyres help smooth out rough roads. And full-length mudguards, a neatly integrated luggage carrier, built-in dynamo lights and a handy kickstand mean you've everything you need for short trips across town and longer forays into the countryside.
