ADVENTURE WAITS
AT THE NEXT CORNER
Beauty is more than skin deep: the Aim's sleek looks are thanks to its Smooth Welded head tube and seat tube junctions. It incorporates a threaded bottom bracket and internal cable routing for long-lasting service and simple maintenance. There's even a flat disc mount that integrates seamlessly with our kickstand mount, and integrated mounting points for ACID mudguards and carrier. Updated geometry includes a lower top tube for more confident handling, and there's plenty of room to run wide, grippy and comfortable 2.25in tyres. Our SizeSplit system has an expanded range, too, so however tall you are there'll be an Aim that fits perfectly.
Frame Material
Sizes
More Information

Bike category of use: 3
You can find more information about Bike Classification at the following link.
115
kg
Maximum rider and bike weight
The weight includes the bike and the rider incl. clothing, as well as any equipment that may be on the rider's body (e.g. backpack) and must not be exceeded.
140
kg
Maximum system weight
The maximum system weight refers to the combined weight of the rider and bike (which is subject to a separate weight limit that must not be exceeded) plus any accessories attached to the bike, such as a trailer, luggage carrier, etc.
Further details can be found in the system weight table.
Geometry
14" / 27.5 / XS | 16" / 27.5 / S | 18" / 29 / M | 20" / 29 / L | 22" / 29 / XL | 24" / 29 / XXL | |
Seat tube | 340 | 370 | 420 | 470 | 515 | 560 |
Top Tube Horizontal | 555 | 575 | 595 | 615 | 635 | 655 |
Seat angle | 74° | 73.5° | 73.5° | 73.5° | 73.5° | 73.5° |
Head tube angle | 68.5° | 68.5° | 68.5° | 68.5° | 68.5° | 68.5° |
Chainstays | 427 | 427 | 450 | 450 | 450 | 450 |
Head tube | 108 | 111 | 111 | 122 | 142 | 157 |
Wheelbase | 1068 | 1082 | 1125 | 1146 | 1168 | 1190 |
BB-Height to Hub | 52 | 52 | 65 | 65 | 65 | 65 |
Protrusion height - 80mm | 707 | 720 | 759 | 792 | 824 | 858 |
Reach | 384 | 398 | 409 | 426 | 441 | 457 |
Stack | 595 | 598 | 627 | 637 | 656 | 670 |
Ergonomics
14" / 27.5 / XS | 16" / 27.5 / S | 18" / 29 / M | 20" / 29 / L | 22" / 29 / XL | 24" / 29 / XXL | |
Length seat post | 350 | 350 | 400 | 400 | 400 | 400 |
Diameter seatpost | 27.2 | 27.2 | 27.2 | 27.2 | 27.2 | 27.2 |
Angle stem | 6° | 6° | 6° | 6° | 6° | 6° |
Crank length | 170 | 170 | 170 | 170 | 170 | 170 |
Diameter tire maximum | 708 | 708 | 747 | 747 | 747 | 747 |
Width tire maximum | 57 | 57 | 57 | 57 | 57 | 57 |
Stem length | 45 | 45 | 60 | 60 | 75 | 75 |
Handlebar width | 680 | 680 | 680 | 680 | 680 | 680 |
All values are given in millimetres or degrees.
